Ultra-fast 25μs response. Simple two-button operation enables intuitive sampling. One-touch toggle between light-on/dark-on modes for rapid field calibration.
5 adjustable response time settings from 25μs to 800μs, ideal for high-speed detection
Simple two-step operation for quick sampling and detection, user-friendly design
Simultaneous display of real-time and threshold values for clear, intuitive monitoring and comparison
|
Model
|
OF-HD50N | OF-HD50P | |
|
Output
|
Output Type
|
NPN | PNP |
|
Number of Control Outputs
|
1 | ||
|
Output Cable
|
2m, lead type
|
||
|
Protective Circuit
|
Reverse Power Connection, Output Overcurrent, and Output Surge Protection
|
||
|
Switching Mode
|
Light-on/Dark-on, switchable
|
||
|
Light Source Wavelength
|
Red LED, wavelength 660nm
|
||
|
Response Time
|
P0: 25 us; P1: 50 us; P2: 100 us; P3: 200 us; P4: 800 us | ||
|
Control Output
|
NPN/PNP open collector 24V, 1 output less than 100mA
|
||
|
Current Consumption
|
≤20mA | ||
|
Power Supply
|
Power Supply Voltage
|
12 to 24 VDC [including ripple (PP) less than 10%]
|
|
|
Power Consumption
|
Standard mode, when 24V, less than 300mW
|
||
|
Environmental Resistance
|
Ambient Light
|
Incandescent light: less than 20,000lux, sunlight: less than 30,000lux
|
|
|
Ambient Temperature
|
-10°C to +55°C (no freezing)
|
||
|
Vibration Resistance
|
10 to 55Hz, double amplitude 1.5mm, 2 hours each in XY and Z directions
|
||
|
Shock Resistance
|
500m/s2, 3 times in each X, Y, Z direction
|
||
|
Enclosure Material
|
PC, Polycarbonate
|
||
|
Weight
|
Approximately 55g
|
||
